Ensure your refrigerator’s compressor gets the reliable push it needs with the WR09X10107 – an OEM overload/PTC start relay assembly from GE Appliances. This component is a critical element in the compressor circuit: it provides the initial starting “kick” and protects the motor from over-current conditions.
Because compressor and sealed-system faults can stem from multiple causes, please check with your maintenance technician prior to ordering to confirm this part matches both your appliance’s full model number and the specific fault diagnosis.
Features & Benefits
-
Genuine OEM part from GE Appliances — assures proper fit and performance. geapplianceparts.com+1
-
Built-in overload protection and PTC (positive temperature coefficient) start relay combine two functions in one unit, helping simplify repair and reduce potential fail-points.
-
Direct replacement for many GE refrigerators that list this part number — restores compressor starting capability and avoids repeated hard-starts or buzzing motors.
-
Protects compressor by shutting off current surges and prevents damage from extended start attempts or locked rotor conditions.
-
Compact, simple to install when matched correctly, helping minimize time and cost for repair when technician verifies compatibility.
Common Symptoms That Indicate Replacement
-
The refrigerator’s compressor tries to start (buzzes or clicks) but fails to run, or repeatedly attempts to start and stops.
-
The refrigerator isn’t cooling properly while the compressor appears to try to start and then shuts down or overheats.
-
The relay/overload assembly shows signs of physical damage: melted casing, burn marks, or rattling internal parts when gently shaken.
-
Frequent circuit breaker trips or overloads associated with the compressor start cycle.
-
After a fresh repair, if compressor runs for only brief periods or overheats quickly, the start device may be the source of issue.
If any of these symptoms appear, have your maintenance technician verify the compressor circuit, sealed-system, and correct part match before ordering.
Compatible (Partial) Model List
Below is a partial list of compatible models for WR09X10107 — always verify your appliance’s exact model number with a technician for full compatibility.
-
GSH25JSTASS
-
GSHH5 … models in the GSH / HSS / GSC / HSM / HTS series listed by some aftermarket sellers.
-
GE side-by-side or bottom-freezer refrigerators that originally used a 5SP start device. (Note: many hundreds of model variants exist)
Note: This is not exhaustive — please consult your service literature or parts diagram.
Cross Reference
This part is equivalent to and replaces the following numbers:
-
AP3884299 eBay
-
PS1020294 eBay
-
Former part numbers like WR08X10075, WR08X10068, WR07X10078 may reference older start devices in similar compressor circuits. appliancerepair.homedepot.com
Compatibility Notes
-
Matching the full model number of your refrigerator is critical — many appliances may look similar but use different start devices depending on compressor brand, refrigerant type, and production date.
-
If the cause of your refrigerator’s cooling failure is a sealed-system fault, compressor failure, or main board fault, simply replacing the start relay may not fix the root issue. Technician diagnosis is recommended.
-
Installation requires disconnection of power and ensuring the relay/overload is securely mounted to the compressor and correctly wired; improper installation may lead to repeated failure or safety hazards.
-
After installation, monitor the unit through one full start-stop cycle to ensure proper compressor function and no unusual sounds or overheating.
